| Intelligent Automatic recognition of different needle electrodes types Single key switch to needle tract ablation mode Automatically save real-time parameters Safe Stable output of radiofrequency power Bipolar negative surgical plate design Multiple abnormal alarm functions | Accurate Real-time monitoring of impedance and power Accurate temperature control mode Impedance and pulse control Efficient Compatible with different types of needle electrodes Tri-needle mode available High complete ablation rate |
 | Water Injection Electrode The electrode exposed tip can be adjusted within a range from 5mm to 40mm. During the ablation procedure,saline can be slowly infused into the tumor through the side holes 5mm from the tip end. This cools the electrodeand balances theimpedance.Suitable for solid tumors with relatively high impedance. |
 | Internal Cooling S Electrode The internally cooled 18G diameter electrode supports moving shot technique and temperature-controlled ablation. The ergonomic handle design ensures comfortable grasping during the moving-shot operation. Suitable for shallow tumors. |
 | Internal Cooling L Electrode Hollow design of the needle shaft allows a controlled saline flow, which helps to avoid carbonation and adhesion.Under impulse mode, impedance inside the tumor is controlled within an appropriate range and produces a morespherical ablation shape.Suitable for relatively big size tumors. |
